    Meitav-tec's SUPER Thermostats -
multiple configurations in a single product



Ultimate choice for wholesalers

Meitav-tec constantly endeavors to develop advanced, SUPER products, which offer numerous configurations and options in a single product to allow its clients both high standard and economy.

Keep in stock & instantly deliver to client

Indeed, Meitav-tec's SUPER thermostats feature high versatility and are  therefore  the  ultimate  choice  for wholesalers or HVAC project contractors who can keep Super thermostats in stock to be supplied to client right away.



Solution for every application

Whether you need Heat/Cool, Heat Pump or Cool Only, 1 /2 /3 /4  Cooling / Heating stages, proportional/ on-off outputs, Meitav-tec's 'plug & play' thermostats have them all.

Using DIP switches, end-users can easily configure the thermostat according to their needs, such as, a 2-Pipe or a 4-Pipe application, with or without Auto-Change-Over mode, 1 or 3 fan speeds, internal / external sensor, etc.




Meitav-tec's SUPER thermostats are versatile, suitable for modern life, and at the same time, very easy and straightforward to use.
Take a look at some of them:




Super thermostats usually
support these standard
features:
 Ÿ  Remote Control operation
 Ÿ  Lock Button option
 Ÿ  Auto-Fan
 Ÿ  External Temperature
    Sensor input
Ÿ  Adjustable Temperature
    Limits
Ÿ  Auto-change-over
 Ÿ  Economy mode
 Ÿ  Emergency Heat
    algorithm
 Ÿ  Cool Only option



  Thermostat name

Fan Speeds

Maximum Heating stages

Maximum Cooling stages

Cool/Heat output Type

Temp. scale C/F
  ETN24-SUPER-SH/SF/SI

1 or 3

4

3

ON-OFF

C

  FMH220-FC-SUPER3

3

1

1

ON-OFF

C/F
  ETN24-PH-FC-SUPER

1,2 & 3

1

1

Cool –
Prop.(0-10V)
Heat – ON-OFF

C/F
  ETN24-P-PD-FC-SUPER2

1,2 & 3

1

1

1 or 2 Prop
(0-10V) Outputs

C/F
  FMH220-P-FC-SUPER

1 or 3

1

1

Prop. (0-10V)

C
  ETN24-PM2

1 or 3

1

1

Prop. (3 wire)

C

  Programmable
  (Weekly Program)


  ETN24-SUPER-PROG-EU

1

3

2

ON-OFF

C/F

  ETN24-SUPER-3S-FP-
  PROG-C-EU

3

1

1

ON-OFF

C

ETN - 24VAC, wall mount              FMH - 230VAC, flush mount
Note:  24VAC Super thermostats can be easily adopted to 230VAC system using Meitav-tec's PS-600,
          a 230VAC to 24VDC Power Supply
